Description

Key Features
Isolates Components in Sound Systems to Eliminate Ground Issues High Quality Transformers XLR, 1/4-inch and RCA Inputs and Outputs Rugged Anodized Aluminum Case Passive Design
Specifications
Frequency Response 10Hz-50kHz +/-.5dB@+4dBu
Total Harmonic Distortion .01% Typical @ 1kHz, +18dBu, <.05% @ 100Hz, +24dBu
Insertion Loss .4dB@100k Ω load,
5.5dB @ 600 Ω load
Input Connectors XLR-F Balanced,1/4-inch TRS Balanced / Unbalanced, and RCA Jacks
Output Connectors XLR-M Balanced, 1/4-inch TRS Balanced / Unbalanced and RCA Jacks
Power Requirements Passive
Dimensions 1.75″H x 4.2″W x 3.5″D (44.5mm x 107mm x 89mm)
Weight .75 lbs (0.34kg)
